Skywatcher RC8 EQ5 Pro Package

RM 7,999.00 RM 819,900.00




Skywatcher  USA RC8 EQ 5 Pro Telescope

Skywatcher RC 8 Telescope Package Combined With 8'' Coma Free Rithcey Chretien Telescope With High Quality EQ5 Pro Mount Provide High Performance And Tracking Accuracy And Is The Mount For Advance Imager, Looking For A Very Sturdy High Payload Mound.

Features 8'' (203mm) Rithcey Chretien Coma Free Telescope With Dual Speed Focuser Providing Flat Field Coma Free Visual And Imaging Experience. 99% Reflectivity Dielectric Coating Come Standard With This RC Telescope

Skywatcher EQ 5 Pro Mount Is Suitable For Astronomer Looking For High Accuracy And Stable Imaging Platform Meant For Portability. Skywatcher EQ 5 Pro Have Features Similar To Larger HEQ 5 Pro And NEQ Pro 6, But In A Smaller More Portable Package. The Skywatcher EQ 5 Pro Mount Is A Serious Mouting For Those Looking For A Proven High Tracking Accuracy Mount, Providing Accuracy Within Range Of +/-10 Arc Second Periodic Error. The Smooth Microstepper Motor Provide Constant Tracking Accuracy And With Autoguiding, Accuracy Of Less Than +/-2 Arc Second Can Be Achieved.

The Skywatcher Eq 5 Pro Mount Can Carry Payload Of Up To 10Kg (7Kg For Imaging) Capable Of Holding Optical Tube With Accessories Up To 6'' Size Catadioptric Or 5'' Refractors For Imaging, Up To 9.25'' Telescope For Visual Usage. The Skywatcher EQ 5 Pro Mount Is The Choice For Those Keen On A High Precision Mount With Future Room For Expansion And Multiple Capability In Both Visual And Imaging. Include Synscan System Allowing Tracking Of Over 42,000 Object Database

Features

 99% Reflectivity Dieletric Coated Aluminium

These Mirror Of Telescope Are Specially Coated To Provide Maximum (99%) Light Reflectivity To Get The Best Contrast Available For Image Or Visual Usage. Compund RC Telescope Are Very Compact Due To The Optical Design



Precision Dual Speed 1:10 MicroFocuser

Most Standard SCT Comes With Standard Focuser, Our RC Telescope Comes With High Quality Dual Speed Microfocuser To Allow Precision Focus And Sharp Image. Our RC Telescope Comes Standard With 2'' Precision Focuser

Features

 High Percision Microstepper Motor

Skywatcher EQ 5 Pro Mount Feature High Precision Microstepper Motor, Providing Very High Resolution - 0.288 Arc Second Per Step. The Mount Is Capable Of Achiving Less Than +/-2 Arc Second Periodic Error With Auto Guiding



Adjustable Stainless Steel Tripod

Skywatcher EQ 5 Pro Comes Standard With 1.75'' Stainless Steel Tubular Tripod To Provide Stability And Sturdy Platform For Imaging. The Tripod Is Relatively Light Weight For Transportability. Best Choice For Portability And Stability



Computerized Go-To System

Skywatcher EQ 5 Pro Mount Feature Go-To Technology. Built-In Internal Computerized System With 42,000+ Object Database, Which Is Fully Upgradable For Future Database Expansion. The Controller Controls The Precise Dual Axis Servo Motor Allowing Accurate Go-To And Tracking



Specifications



8'' RC Telescope

  • 8'' (203mm) F/8 Ritchey Chretien Optical Telescope
  • F/8 Focal Ratio
  • 1624mm Focal Length
  • 13.4lbs Weigth
  • Dual V-Vixen Dovetail Plate
  • Central Obstruction : 85mm (17.5% By Area)
  • Internal Baffled
  • Dual Speed 1:10 Precision Focuser

Mount

  • Positioning Accuracy up to 1 arc minute. Accuracy enhanced by software collimation error (mount mechanical error) compensation.
  • Payload Capacity : 10Kg (Visual) 7Kg (Imaging)
  • Stepper motors with 1.8° step angle and 64 micro steps driven.
  • Slewing speed up to 3.4°/sec (800X).
  • Auto Guider Interface for astro-photography.
  • Guiding speed selectable from 0.25X, 0.50X, 0.75X, or 1X.
  • Object database containing complete Messier, NGC, and IC catalogues.
  • Minimal vibration for steady long-exposure photography.
  • Periodic Error Correction.
  • PC compatibility.
  • Upgradeable hand control via internet download
  • Telescope Mounting Method: Tube Ring
  • Tripod: Stainless Steel Legs
  • Counterweight Shaft Material: Stainless Steel
  • Mount Weight (without counterweight): 4.6Kgs
  • Mount Height: 35cm
  • Total weight: 9kgs (without counterweights)
  • Motor Type: Microstep driven 1.8 degree stepper motors
  • Motor Resolution: 0.288 arc sec
  • Power Supply: 12V DC 2Amp (Tip positive)
  •



Included Items



  • 8'' F/8 Ritchey Chretien Telescope
  • 2'' Dual Speed 1:10 Microfocuser
  • 1X 50mm Spacer
  • 2X 25mm Spacer
  • 1.25'' Star Diagonal
  • 40mm Super Plossl (40x)
  • 6x30 Optical Finder Scope
  • Skywatcher EQ 5 Pro Go To Mount
  • 1.75'' Stainless Steel Tripod
  • 1x 5.1Kg Counterweight
  • Skywatcher Synscan Remote Controller
  • 1 Year Skywatcher Malaysia Warranty
